Ford F250 Bed Size Chart: Year and Cab 1999 to 2026
The Ford F250 bed size chart comes down to two main pickup box lengths: a 6.75-foot short bed and an 8-foot long bed. Regular Cab trucks use the 8-foot box, while SuperCab and Crew Cab configurations have been offered with short and long beds depending on model year.
The advertised 6.75-foot and 8-foot labels are nominal sizes. Actual inside floor length, bed width, height, and cargo volume changed across Super Duty generations.
The biggest fitment break is 2017. Ford replaced the steel pickup box with an aluminum body and cargo box, and several inside measurements changed even though the nominal bed names stayed the same.
Ford F-250 Bed Size Chart 1999–2026
Ford F-250 Super Duty pickups primarily use 6.75-foot and 8-foot beds. Actual inside dimensions changed across generations, with 2017 marking the biggest modern fitment breakpoint.
6.75-Foot Short Bed
8-Foot Long Bed
| Cab Style | 6.75-Foot Bed | 8-Foot Bed | Typical Use |
|---|---|---|---|
| Regular Cab | No | Yes | Work and maximum cargo length |
| SuperCab | Yes | Yes | Cargo and passenger balance |
| Crew Cab | Yes | Yes | Passenger space with short or long box |
Measurements shown are cargo-box dimensions summarized from the verified specifications used in this article. Nominal 6.75-foot and 8-foot labels are not the same as exact inside floor measurements.
Ford F250 Bed Size Chart From 1999 to 2026
The table below gives the fastest way to identify Ford F-250 bed sizes by model year and cab configuration.
| Model Years | Regular Cab | SuperCab | Crew Cab | Short Bed Floor Length | Long Bed Floor Length |
|---|---|---|---|---|---|
| 1999 to 2007 | 8 ft | 6.75 ft or 8 ft | 6.75 ft or 8 ft | 82.4 in | 98.6 in |
| 2008 to 2010 | 8 ft | 6.75 ft or 8 ft | 6.75 ft or 8 ft | 81.8 in | 98.0 in |
| 2011 to 2016 | 8 ft | 6.75 ft or 8 ft | 6.75 ft or 8 ft | 81.8 in | 98.0 in |
| 2017 to 2022 | 8 ft | 6.75 ft or 8 ft | 6.75 ft or 8 ft | 81.9 in | 98.1 in |
| 2023 to 2026 | 8 ft | 6.75 ft or 8 ft | 6.75 ft or 8 ft | 81.9 in | 98.1 in |
Ford documentation for the early Super Duty platform shows an 82.4-inch cargo floor for the nominal 6.75-foot box and 98.6 inches for the 8-foot box. The same documentation lists 50.9 inches between the wheelhouses.
The 2008 redesign shortened those measurements slightly to 81.8 and 98.0 inches. Ford retained those floor dimensions through the 2016 model year.
For 2017 and newer trucks, the measurements became 81.9 and 98.1 inches. Ford still uses those dimensions on the 2026 F-250 Super Duty.
SWB means short wheelbase and normally identifies the 6.75-foot cargo box. LWB means long wheelbase and identifies the 8-foot cargo box.
What Are the Exact F250 Bed Dimensions
Bed length is only one measurement that matters. Tonneau covers, bed liners, slide-in equipment, dividers, toolboxes, and other accessories may also depend on width and bed-rail dimensions.
Here is the clearest comparison of the main F-250 bed generations.
| Model Years | Bed | Floor Length | Max Floor Width | Wheelhouse Width | Bed Height | Cargo Volume |
|---|---|---|---|---|---|---|
| 2001 era | 6.75 ft | 82.4 in | Not consistently listed | 50.9 in | 20.0 in | 64.7 cu ft |
| 2001 era | 8 ft | 98.6 in | Not consistently listed | 50.9 in | 20.0 in | 77.7 cu ft |
| 2008 to 2010 | 6.75 ft | 81.8 in | 69.3 in | 50.9 in | Verify by year | 64.4 cu ft |
| 2008 to 2010 | 8 ft | 98.0 in | 69.3 in | 50.9 in | Verify by year | 77.4 cu ft |
| 2011 to 2016 | 6.75 ft | 81.8 in | 69.3 in | 50.9 in | Verify by year | 64.1 cu ft |
| 2011 to 2016 | 8 ft | 98.0 in | 69.3 in | 50.9 in | Verify by year | 77.3 cu ft |
| 2017 to 2026 | 6.75 ft | 81.9 in | 66.9 in | 50.5 in | 21.1 in | 65.4 cu ft |
| 2017 to 2026 | 8 ft | 98.1 in | 66.9 in | 50.5 in | 21.1 in | 78.5 cu ft |
Ford’s 2001 specifications list a 20-inch inside box height, 50.9-inch wheelhouse width, 82.4-inch short-box floor, and 98.6-inch long-box floor.
By 2008, Ford listed a 69.3-inch maximum floor width with 81.8-inch and 98.0-inch floor lengths. Those core bed measurements remained present in Ford’s 2010, 2011, 2012, and 2015 documentation.
6.75 Foot Short Bed Dimensions
The current 6.75-foot F-250 bed measures 81.9 inches along the floor. Ford lists an 80.3-inch length at the top of the box, 66.9 inches of maximum floor width, and 50.5 inches between the wheelhouses.
Bed height is 21.1 inches, while total advertised cargo volume is 65.4 cubic feet.
Do not convert 6.75 feet directly into inches and assume that result is the usable cargo floor. Ford’s nominal box designation and its actual internal measurements are different.
8 Foot Long Bed Dimensions
The current 8-foot F-250 box measures 98.1 inches at the floor and 96.4 inches at the top of the box.
Maximum floor width remains 66.9 inches, with 50.5 inches between the wheelhouses and a 21.1-inch bed height. Ford lists total box volume at 78.5 cubic feet.
That gives the current long box 16.2 inches more floor length and about 13.1 cubic feet more listed cargo volume than the short box.
Which F250 Cab Gets Each Bed Size
Cab configuration determines which F-250 bed combinations are available.
Ford’s current configuration data shows the following arrangement.
| Cab | 6.75 Foot Bed | 8 Foot Bed |
|---|---|---|
| Regular Cab | No | Yes |
| SuperCab | Yes | Yes |
| Crew Cab | Yes | Yes |
Regular Cab Bed Options
The F-250 Regular Cab is paired with the 8-foot pickup box in Ford’s current lineup. The same basic Regular Cab and long-bed relationship appears throughout the older Super Duty documentation reviewed for this chart.
This configuration suits owners who prioritize full cargo-floor length over rear passenger space.
SuperCab Bed Options
SuperCab F-250 trucks can be found with either bed length.
Ford’s 2019 order documentation lists a 148-inch-wheelbase SuperCab with the 6.75-foot box and a 164.2-inch-wheelbase version with the 8-foot box.
The 2026 lineup continues the same basic choice. Ford lists SuperCab configurations with both 6.75-foot and 8-foot boxes.
Crew Cab Bed Options
Crew Cab buyers also have short- and long-bed choices.
For 2026, Ford lists the Crew Cab short-bed truck at roughly a 159.7-inch wheelbase and the 8-foot configuration at approximately 175.9 inches.
The longer wheelbase affects maneuverability and total truck length, so bed selection changes more than cargo space.
How F250 Bed Dimensions Changed Across 5 Generations
Ford kept the familiar 6.75-foot and 8-foot terminology for decades, but the actual pickup box did not remain dimensionally identical.
That matters most when you are ordering accessories that attach to the rails or follow the exact shape of the box.
1999 to 2007 F250 Bed Sizes
First-generation Super Duty pickups used nominal 6.75-foot and 8-foot boxes.
Ford specifications from this platform show a 82.4-inch short-bed floor and 98.6-inch long-bed floor, with 50.9 inches between the wheelhouses and a 20-inch inside bed height.
Regular Cab trucks used the long box, while SuperCab and Crew Cab configurations were offered in short- and long-wheelbase forms.
2008 to 2010 F250 Bed Sizes
The 2008 Super Duty redesign brought a dimensional change.
Ford’s 2008 specifications list an 81.8-inch short bed, 98.0-inch long bed, 69.3-inch maximum floor width, and 50.9 inches between the wheelhouses.
Ford’s 2010 documentation reports the same floor lengths and widths, confirming those measurements through the end of this generation.
2011 to 2016 F250 Bed Sizes
Ford redesigned the Super Duty again for 2011, but the core pickup-box floor dimensions stayed at 81.8 inches and 98.0 inches.
The 2011 technical specifications list 69.3 inches of maximum floor width and 50.9 inches between the wheelhouses. Cargo volume was 64.1 cubic feet for the short bed and 77.3 cubic feet for the long bed.
Ford’s 2015 documentation reports the same measurements, supporting their use through the late pre-aluminum generation.
2017 to 2022 F250 Bed Sizes
The 2017 redesign is the critical accessory-fitment breakpoint.
Ford introduced an aluminum-alloy body and cargo box for the new Super Duty.
By 2018, official specifications show 81.9-inch and 98.1-inch floor lengths, a narrower 66.9-inch maximum floor width, 50.5 inches between the wheelhouses, and 21.1 inches of bed height.
These dimensions explain why an accessory designed around the inner rails of a 2011–2016 bed should not automatically be assumed to fit a 2017 truck.
2023 to 2026 F250 Bed Sizes
The latest-generation Super Duty retains the 6.75-foot and 8-foot pickup-box choices.
Ford’s 2023 specifications list 81.9 and 98.1 inches at the floor, 66.9 inches of maximum width, 50.5 inches between the wheelhouses, and 21.1 inches of height.
The official 2026 technical specifications show those same core bed measurements, so the current generation does not introduce another major dimensional change.
How to Measure Your F250 Bed Correctly
Measure your F-250 before ordering an expensive bed-specific accessory, especially if the truck is used or has an uncertain model-year history.
- Park the truck on level ground.
- Close the tailgate completely.
- Place the end of a tape measure against the inside front wall of the bed.
- Run the tape along the bed floor.
- Measure to the inside face of the closed tailgate.
- Compare the measurement with the correct model-year specifications.
- Confirm your model year and cab before ordering the part.
Ford separates floor length from length at the top of the box in its own specifications. For the current short bed, those measurements are 81.9 inches at the floor and 80.3 inches at the top. The long bed measures 98.1 and 96.4 inches respectively.
Measure from inside the box. Measuring the exterior bedside will not give you Ford’s published cargo-floor dimension.
Why Bed Size Alone Does Not Confirm Accessory Fit
Two Ford F-250 trucks can both be advertised with a 6.75-foot bed and still require different accessories.
The 2017 redesign is the clearest example. A pre-2017 short bed has different internal dimensions from the 2017+ aluminum box.
Ford’s current accessories catalog itself groups many bed covers specifically as 2017–2026 Super Duty applications. Ford lists separate products for 6.75-foot and 8-foot beds.
Owner reports from the 2017 model launch also document pre-2017 tonneau covers failing to interchange because of rail dimensions. One owner reported that TruXedo confirmed the 2017 bed was longer and narrower between the rails than the previous version.
Before ordering a tonneau cover, cap, liner, bed rack, or rail-mounted toolbox, check:
- Model year
- Bed length
- Cab configuration
- Product-specific fitment range
- Bed-rail mounting method
- Factory bed options
- Fifth-wheel or gooseneck preparation equipment
A tape measurement is useful for identifying the bed. The accessory manufacturer’s fitment list should make the final decision.
Which F250 Bed Size Works Better for 5 Common Uses
The 8-foot bed provides more cargo floor, while the 6.75-foot bed reduces overall truck length.
| Use | Better Starting Choice | Main Reason |
|---|---|---|
| Maximum cargo length | 8 ft | 16.2 inches more current floor length |
| Construction materials | 8 ft | Longer supported cargo floor |
| Fifth-wheel setup | Often 8 ft | More distance between cab and rear axle area |
| Daily driving | 6.75 ft | Shorter wheelbase and overall length |
| Crew Cab family truck | Often 6.75 ft | Easier packaging with full rear seating |
Bed length alone does not determine towing or payload capacity. Engine, cab, drivetrain, axle ratio, Gross Vehicle Weight Rating, and other equipment can change the rating.
For trailer ratings across Ford trucks, use our Ford towing capacity chart rather than estimating capacity from bed length.
Current-generation owners comparing Heavy Duty configurations may also find our 2024 Ford F-250 towing capacity chart useful when matching cab and bed configuration to trailer requirements.
For comparison with the next Super Duty class, the Ford F-350 payload capacity chart explains how payload changes across F-350 configurations.
How to Choose the Correct F250 Bed Size
The Ford F250 bed size chart shows two main boxes throughout the Super Duty era: a nominal 6.75-foot short bed and an 8-foot long bed.
The exact measurements depend on generation. Early trucks used 82.4-inch and 98.6-inch floors, 2008–2016 trucks used 81.8 and 98.0 inches, and 2017–2026 trucks use 81.9 and 98.1 inches.
Regular Cab trucks use the 8-foot bed. SuperCab and Crew Cab configurations can use either box in documented model years.
Before buying a bed-specific part, verify your model year, cab, measured floor length, and the manufacturer’s exact fitment range.
Ford F250 Bed Size FAQ
What Size Bed Does a Ford F250 Have?
The Ford F-250 primarily comes with a 6.75-foot bed or an 8-foot bed. Regular Cab trucks use the long box, while SuperCab and Crew Cab models have been offered with both bed lengths depending on year and configuration.
How Long Is a Ford F250 Short Bed?
A current 2017–2026 F-250 short bed measures 81.9 inches along the floor. The 2008–2016 short bed measures 81.8 inches, while earlier Super Duty documentation lists 82.4 inches.
How Long Is an F250 8 Foot Bed Inside?
The current F-250 8-foot bed measures 98.1 inches at the floor. Ford lists 98.0 inches for 2008–2016 trucks and 98.6 inches in earlier Super Duty specifications.
Does an F250 Crew Cab Come With an 8 Foot Bed?
Yes. Ford offers documented Crew Cab F-250 configurations with the 8-foot box as well as the 6.75-foot box.
The 2026 Crew Cab long-bed configuration has approximately a 175.9-inch wheelbase compared with about 159.7 inches for the short-bed configuration.
Does an F250 Regular Cab Have a Short Bed?
No short-bed Regular Cab configuration appears in the Ford Super Duty pickup documentation reviewed for this 1999–2026 chart. Ford pairs the current Regular Cab F-250 with the 8-foot pickup box.
Are F250 and F350 Beds the Same Size?
F-250 and F-350 pickup models commonly share the same nominal 6.75-foot and 8-foot Super Duty boxes within the same generation. Do not use that fact alone to confirm accessory fitment because rear-wheel configuration, model year, and product mounting requirements can still matter.
For F-350 configuration data, see our 2025 Ford F-350 towing capacity chart.
Will a 2016 F250 Bed Cover Fit a 2017 F250?
Do not assume it will. The 2017 Super Duty received a redesigned aluminum cargo box, and its published dimensions differ from the 2016 box.
Ford now catalogs many bed covers specifically for the 2017–2026 Super Duty application range, so verify the manufacturer’s exact part number before reusing a 2016 cover.
