Toyota Tacoma Wheel Offset Chart for All 1995 to 2026 Models
The Toyota Tacoma wheel offset chart depends on model year, wheel width, drivetrain, and trim. Common factory-reference offsets include +25 mm and +30 mm on 2016–2023 wheels, while many 2024–2026 standard wheels use +55 mm or +60 mm. TRD-specific wheels can be considerably different.
There is no single offset that fits every Tacoma. Some 1995–2015 base 2WD trucks have five-lug hubs, and the 2024 redesign changed the six-lug hub bore and wheel hardware. Use the chart below to identify a matching wheel configuration, then check the actual wheel part number before ordering replacements.
Selected OEM-style wheel configurations across four generations, plus genuine Toyota TRD accessories. All offsets are in millimeters.
Scroll horizontally on mobile. These are examples, not one-size-fits-all specifications for every model year and trim.
| Tacoma model / example | Wheel | Offset | Bolt pattern | Reference type |
|---|---|---|---|---|
| GEN 12002 base 2WD | 14 × 5 | +34 | 5 × 114.3 | Fitment database |
| GEN 12002 4WD | 16 × 7 | +15 | 6 × 139.7 | Toyota parts catalog |
| GEN 22005 base 2WD | 15 × 6 | +34 | 5 × 114.3 | Fitment database |
| GEN 2Selected 4WD / PreRunner | 16 × 7 | +30 | 6 × 139.7 | Fitment reference |
| GEN 2Selected TRD Off-Road | 16 × 7 | +32 | 6 × 139.7 | Retailer reference |
| GEN 3Selected 2016–2023 standard | 16 × 7 | +25 | 6 × 139.7 | Fitment reference |
| GEN 3Selected 2016–2023 alloy | 17 × 7.5 | +30 | 6 × 139.7 | Fitment reference |
| TRD16-inch Toyota TRD accessory | 16 × 7 | +13 | 6 × 139.7 | PT758-35170-02 |
| GEN 4Selected 2024–2026 standard | 17 × 7 | +60 | 6 × 139.7 | Fitment reference |
| GEN 4Selected 2024–2026 alloy | 17 × 7.5 | +55 | 6 × 139.7 | Fitment reference |
| GEN 4Selected 2024–2026 18-in | 18 × 7.5 | +55 | 6 × 139.7 | Fitment reference |
| TRD2024+ Toyota TRD Pro wheel | 18 × 8.5 | +20 | 6 × 139.7 | PT946-35240-2F |
Example: On wheels of equal width, moving from ET55 to ET25 shifts the rim 30 mm outward.
Toyota Tacoma Wheel Offset Chart for 1995 to 2026
The table lists documented examples of factory-specification and genuine Toyota wheels, not every wheel ever fitted to a Tacoma. The ranges indicate generations in which these configurations are relevant; they do not mean every trim received the same rim. Historical specifications were cross-checked against Toyota Tacoma fitment records.
| Model Years and Configuration | Wheel Size | Offset | Bolt Pattern | Data Status |
|---|---|---|---|---|
| 1995–2004, selected base 2WD, 2002 example | 14×5 in | +34 mm | 5×114.3 | Fitment reference |
| 1995–2004, selected base 2WD, 2002 example | 15×6 in | +40 mm | 5×114.3 | Fitment reference |
| 1995–2004, selected 4WD, 2002 example | 15×6 in | +10 mm | 6×139.7 | Fitment reference |
| 1998–2004, selected PreRunner or 4WD | 16×7 in | +15 mm | 6×139.7 | Fitment reference |
| 2005–2015, base 2WD, 2005 example | 15×6 in | +34 mm | 5×114.3 | Fitment reference |
| 2005–2015, selected six-lug 4WD | 16×7 in | +30 mm | 6×139.7 | Fitment reference |
| 2005–2015, selected TRD Off-Road 6-lug wheel | 16×7 in | +32 mm | 6×139.7 | Retailer reference |
| 2005–2015, selected TRD Sport six-lug wheel | 17×7.5 in | +30 mm | 6×139.7 | Retailer reference |
| 2016–2023, common standard six-lug wheel | 16×7 in | +25 mm | 6×139.7 | Retailer reference |
| 2016–2023, selected six-lug alloy wheel | 17×7.5 in | +30 mm | 6×139.7 | Retailer reference |
| 2016–2023, selected Limited-style wheel | 18×7.5 in | +30 mm | 6×139.7 | Retailer reference |
| Genuine Toyota TRD Pro accessory, check model fit | 16×7 in | +13 mm | 6×139.7 | Toyota part specification |
| 2024–2026, selected standard wheel | 17×7 in | +60 mm | 6×139.7 | Fitment reference |
| 2024–2026, selected standard or TRD wheel | 17×7.5 in | +55 mm | 6×139.7 | Fitment reference |
| 2024–2026, selected 18-inch factory wheel | 18×7.5 in | +55 mm | 6×139.7 | Fitment reference |
| 2024-and-newer genuine Toyota TRD Pro wheel, PT946-35240-2F | 18×8.5 in | +20 mm | 6×139.7 | Toyota dealer part specification |
How to read the chart: A 17×7.5 wheel is 17 inches in diameter and 7.5 inches wide. An offset marked ET30 means its mounting surface sits 30 mm toward the wheel’s outer face from the wheel centerline. Positive offset places more of the wheel inboard than the same-width wheel with a smaller offset.
Accuracy limit: The 2002 and 2005 rows are specific documented examples. Some later rows represent wheel families across several years, not a VIN-specific Toyota build record. Toyota accessories are labeled separately because a genuine Toyota wheel is not automatically the original wheel on every compatible trim. The vehicle’s wheel marking and Toyota parts catalog take priority when data conflicts.
![Auto Ventshade [AVS] In-Channel Rain Guards For 2016 - 2023 Toyota Tacoma…](https://m.media-amazon.com/images/I/31G9D7wM1xL._SS500_.jpg)
Which 1995 to 2015 Tacoma Wheels Have Five Lugs
Earlier Tacomas can look similar but use fundamentally different hubs. Base rear-wheel-drive configurations often have five studs on a 114.3 mm circle, while 4WD and PreRunner configurations generally have six studs on a 139.7 mm circle.
Five Lug Base Tacoma Wheels
On a 2002 base 2WD Tacoma, reference configurations include a 14×5-inch wheel with +34 mm offset and a 15×6-inch wheel with +40 mm offset. The five-lug hub bore on these older configurations is generally 67.1 mm.
A documented 2005 2.7L 2WD example uses a 15×6-inch wheel at +34 mm, with a smaller 60.1 mm center bore. A wheel may match the five-stud pattern yet still have the wrong center opening or brake clearance.
Six Lug PreRunner and 4WD Wheels
A 2002 4WD example uses a 15×6-inch wheel at +10 mm or a 16×7-inch wheel at +15 mm. Second-generation six-lug applications commonly use a 16×7-inch wheel near +30 mm, with some TRD Off-Road wheels listed at +32 mm.
The factory wheel backspacing reference lists selected 2005–2015 and 2016–2023 Toyota wheel configurations. It is useful for comparison but does not replace Toyota’s part-specific specifications. Count the studs before shopping. Never try to mount a five-lug wheel on a six-lug hub using ordinary lug nuts.
What Are 2016 to 2023 Tacoma Stock Wheel Offsets
Third-generation Tacomas use the 6×139.7 mm bolt pattern across their regular factory configurations. The hub bore is approximately 106.1 mm and the factory stud thread is M12×1.5.
SR and SR5 Factory Wheels
A commonly documented 16×7-inch Tacoma wheel has a +25 mm offset. A wheel with this offset places its mounting face 25 mm outward from the rim’s centerline.
Wheel size is not enough to identify the correct replacement. Two 16-inch Tacoma rims may have different offsets, spoke shapes, and brake-clearance profiles.
TRD Off-Road and Sport Wheels
A documented 17×7.5-inch Toyota six-lug wheel uses +30 mm offset. Certain 16-inch wheels use +25 mm, although trim-specific wheel packages can differ.
If you are comparing an SR5 wheel with a TRD Sport or TRD Off-Road wheel, identify the stamped wheel dimensions rather than assuming the trim badge guarantees an offset.
Limited and TRD Pro Wheels
Selected 18×7.5-inch factory wheels are listed at +30 mm. TRD Pro-branded wheels deserve separate attention because the offset often changes to create a wider stance.
For example, Toyota’s genuine 16×7-inch TRD Pro alloy wheel, part PT758-35170-02, specifies +13 mm. That establishes the specification of this particular Toyota accessory. It does not mean every 2016–2023 TRD Pro rolled off the assembly line with that exact part.
What Changed for 2024 to 2026 Tacoma Wheel Offsets
The fourth-generation Tacoma retains the six-lug 6×139.7 mm bolt pattern, but several other dimensions changed. Standard-wheel references now commonly show much higher positive offsets than third-generation factory wheels.
For the 2024–2026 generation, the most useful reference combinations are 17×7 ET60, 17×7.5 ET55, and 18×7.5 ET55. Availability varies by model year, trim, and factory wheel package.
Standard Tacoma Factory Wheel Specifications
A 17×7-inch wheel with +60 mm offset appears in base fourth-generation fitment records. Larger 17×7.5-inch and 18×7.5-inch configurations are commonly shown with +55 mm.
These are reference specifications, not a promise that every SR, SR5, TRD Sport, TRD Off-Road, or Limited has the same wheel. The Toyota Tacoma trim comparison chart can help you identify the correct trim before matching the wheel package.
TRD Pro and Trailhunter Wheels
A genuine 2024-and-newer Toyota TRD Pro replacement wheel, part PT946-35240-2F, is listed as 18×8.5 inches with +20 mm offset by a Toyota dealer’s TRD Pro wheel parts listing.
The Trailhunter also uses specialized 18-inch wheels, but its exact offset should be checked against the wheel part number. Do not assign the TRD Pro’s +20 mm specification to every Trailhunter or every TRD optional wheel.
Fourth Generation Hub and Stud Changes
Most earlier six-lug Tacomas use a 106.1 mm hub bore and M12×1.5 studs. The 2024–2026 Tacoma uses a hub around 95.1 mm and M14×1.5 studs. Some fitment databases round the new hub figure to 95.2 mm; obtain the precise mating dimensions from the wheel manufacturer.
These changes are why matching the bolt pattern alone does not establish safe interchangeability.
How Positive and Negative Offset Change Wheel Position
Wheel offset is the distance between the wheel’s width centerline and its hub-mounting face. It is measured in millimeters and often stamped as ET followed by a number.
Positive Offset and Inward Position
Positive offset puts the mounting face toward the wheel’s outer side. On two wheels of identical width, the higher positive offset sits farther inward. For example, a +55 mm wheel sits 30 mm farther inward than a +25 mm wheel of the same width.
Zero Offset and Centered Position
A zero-offset wheel has its mounting face exactly on the rim’s width centerline. Compared with a positive-offset wheel of equal width, it projects farther toward the fender and provides less inward positioning.
Negative Offset and Outward Position
Negative offset places the mounting face inward of the rim’s centerline. The wheel projects farther outward and may create clearance problems at the fender liner, bumper, or body mount during turns.
An offset change alone cannot predict rubbing because tires, wheel width, ride height, and steering travel also matter.
How to Convert Tacoma Offset to Backspacing
Backspacing measures the distance from the hub-mounting face to the wheel’s innermost rim edge. Unlike offset, it includes the effect of wheel width and is generally expressed in inches.
For a conventional wheel, an approximate conversion is:
Backspacing (inches) ≈ (nominal wheel width + 1) ÷ 2 + offset (mm) ÷ 25.4
The additional inch estimates the combined outer and inner rim flanges. Actual backspacing can vary slightly with flange construction.
For a 17×7.5-inch wheel at +30 mm, the calculation is:
(7.5 + 1) ÷ 2 + 30 ÷ 25.4 = 5.43 inches
A 17×7.5-inch wheel at +55 mm has approximately 6.42 inches of backspacing. With identical wheel width, the +55 mm wheel extends 25 mm farther toward the suspension and 25 mm less toward the fender than the +30 mm wheel.
When wheel width changes, compare both the inner and outer lip positions. A 17×9 wheel at +25 mm will not sit like a 17×7.5 wheel at +25 mm, despite sharing the same offset.
Will Older Tacoma Wheels Fit 2024 to 2026 Models
Some older six-lug wheels may physically mount on newer Tacomas, but compatibility is not automatic. Both generations can share 6×139.7 bolt circles, yet their center bores, wheel offsets, studs, and brake packages differ.
An older wheel with a 106.1 mm center opening is larger than the approximately 95.1 mm hub used on the fourth-generation Tacoma. Correct hub-centric rings may help center a compatible aftermarket-style wheel, but they cannot fix an incorrect bolt pattern, unsuitable lug seat, insufficient stud-hole clearance, or brake-caliper interference.
The reverse swap can be more restrictive. A newer OEM wheel with a roughly 95.1 mm center opening cannot seat over an older 106.1 mm hub without a suitable professionally engineered solution. Do not grind or machine wheels simply because the bolt holes line up.
Before a generation swap, confirm wheel load rating, Toyota-approved fasteners, hub engagement, and brake clearance with the exact part number. A wheel that bolts on while the truck is stationary still needs clearance through steering and suspension movement.
How to Check Aftermarket Wheel Clearance on Tacomas
An aftermarket rim needs more than a matching diameter and bolt circle. Compare the entire wheel-and-tire package against your truck’s original configuration before purchasing.
Identify Factory Wheel Measurements
Check the factory wheel’s stamped diameter, width, and offset. Record the Tacoma’s model year, trim, drivetrain, tire size, bolt pattern, and hub bore. If the wheel has been changed before, use the VIN-specific Toyota parts catalog instead of assuming the installed rim is original.
Compare Replacement Wheel Dimensions
Calculate how the proposed wheel moves relative to stock. For equal-width wheels, reducing offset from +30 mm to +10 mm moves the rim 20 mm outward. A wider wheel adds half of its extra width to each side before the offset difference is applied.
Ask the seller to confirm the wheel’s load rating, center-bore dimensions, lug-nut seat design, TPMS compatibility, and application-specific brake clearance.
Check Tire and Suspension Clearance
A larger tire can rub even when the rim clears the upper control arm. Inspect the fender liner, bumper edge, mud flap, and suspension at full steering lock. Clearance must also remain adequate during suspension compression.
A Toyota Tacoma leveling kit changes ride height, but it does not automatically eliminate interference with the cab mount, steering components, or bodywork.
Confirm Fitment Before Installation
Use the tire manufacturer’s approved rim-width range and compare the tire’s actual dimensions. Truck owners choosing all-terrain or mud-terrain rubber can start with the site’s Toyota Tacoma tire buying guide for category and usage differences.
After installing the approved wheel-and-tire combination, set cold inflation pressure according to the vehicle placard and tire specification. The Tacoma tire pressure chart supplies general year-based context, but the driver’s door placard is the final authority for an unmodified factory tire package.
Which Tacoma Offset Should You Use Before Buying
The Toyota Tacoma wheel offset chart is a starting point, not a universal fitment guarantee. Factory offset varies by wheel design. The 2016–2023 generation commonly uses +25 mm or +30 mm wheels, while many fourth-generation standard wheels use +55 mm or +60 mm. Genuine TRD wheels can be substantially different.
Choose a replacement by matching the exact wheel specifications to the truck’s year, trim, and original part number. For aftermarket wheels, compare inner and outer clearance, load capacity, hub bore, brake fitment, and fastener design before ordering. If any required measurement is missing, obtain it from Toyota or the wheel manufacturer instead of assuming an approximate chart value is safe.
Toyota Tacoma Wheel Offset FAQs by Generation
What Is the Stock Tacoma Wheel Offset?
There is no single stock Tacoma wheel offset. Selected third-generation factory wheels use +25 mm or +30 mm, while common fourth-generation standard-wheel references include +55 mm and +60 mm. Match the measurement to your exact wheel design and year.
Do All Toyota Tacomas Use Six Lug Wheels?
No. Some 1995–2015 base 2WD Tacomas use a 5×114.3 bolt pattern. Most 4WD and PreRunner trucks from those years use six lugs, and 2016-and-newer regular Tacoma configurations use 6×139.7.
Will Third Gen Wheels Fit Fourth Gen Tacomas?
Not automatically. Both generations can share the 6×139.7 bolt pattern, but the 2024 redesign changed hub bore and stud specifications. Check the wheel’s center opening, lug-seat design, stud holes, brake clearance, and load rating before attempting a swap.
Does Zero Offset Cause Tire Rubbing?
It can, but zero offset does not guarantee rubbing. Compared with a positive-offset wheel of equal width, zero offset moves the tire outward. Whether it rubs depends on tire size, wheel width, suspension height, and steering or compression clearance.
How Does Wheel Width Affect Tire Poke?
At a fixed offset, adding one inch of wheel width extends each rim edge outward by approximately half an inch. A lower offset adds further outward movement. Compare both variables with stock, then check the mounted tire’s actual sidewall width.
