2014 Dodge Ram 1500 Problems: A Guide To Diagnosis And Repair

While the 2014 Dodge Ram 1500 remains a benchmark for light-duty truck comfort and capability, a decade of road use has revealed several persistent mechanical and electrical vulnerabilities. Owners frequently encounter frustrating issues ranging from collapsing air suspensions and ‘Hemi ticks’ to complex TIPM electrical failures that can leave the vehicle stranded. This guide provides a professional technical analysis of these common 2014 Ram 1500 problems, offering clear diagnostic steps and viable repair solutions to keep your truck on the road.

Diagnose and Repair 2014 Ram 1500 Air Suspension Failures

The 2014 Ram 1500 was a pioneer in luxury ride quality thanks to its optional Four-Corner Air Suspension system. However, this system has become one of the most significant sources of owner frustration. Unlike traditional air systems that vent to the atmosphere, the Ram uses a closed-loop nitrogen system. When this system fails, the truck often “bottoms out” on its bump stops, resulting in a ride quality that is virtually undrivable.

📤 Share


💾 Download

Identifying Symptoms and Environmental Triggers

The most common symptom is ride height inconsistency, where one corner or the entire vehicle sags overnight. In cold climates, moisture can enter the closed-loop system, causing the manifold valves to freeze and stick. Research indicates that the CarComplaints data highlights air suspension issues as a primary reason for low owner satisfaction scores. If you notice your truck sagging in the front-left corner after an overnight freeze, the system likely has a leak that has led to a compressor burnout from overworking.

📋
Air Suspension Troubleshooting

1

Check Visual Indicators

Inspect the air bags for “dry rot” or cracking. Spray soapy water on the air lines and fittings to diagnose slow leaks.

2

Scan for ASCM Codes

Use a professional scanner to pull codes from the Air Suspension Control Module (ASCM). Look for “Compressor Circuit High” or “Payload Exceeded.”

Repairing these systems is costly. An OEM compressor replacement and system nitrogen purge can easily exceed $2,000. Because of this, many owners choose a permanent solution: converting the air suspension to a traditional coil spring setup. This eliminates the cause of future failures and provides long-term reliability for a fraction of the cost of a full air overhaul, which can range from $1,500 to $4,500.

Troubleshoot Electrical Issues and TIPM Malfunctions

The 2014 Ram 1500 utilizes a Totally Integrated Power Module (TIPM), which is essentially the “brain” of the truck’s electrical system. This component is notorious for internal circuit board failures, leading to what mechanics often call “electrical gremlins.” A failing TIPM can manifest in bizarre ways: windshield wipers activating on their own, the horn honking randomly, or the fuel pump remaining engaged after the engine is turned off.

To troubleshoot a suspect TIPM, use a multimeter to check for consistent power delivery at the fuse block. If you experience a “crank but no start” condition, it is likely the fuel pump relay within the TIPM. While a dealership will recommend a full TIPM replacement costing over $1,000, a common workaround is an external relay bypass kit. This kit bypasses the faulty internal relay and provides a reliable power source to the fuel pump for under $100.

Additionally, the Uconnect infotainment system in the 2014 model is prone to freezing. Before assuming hardware failure, visit the Mopar website to check for software updates. Many connectivity issues are resolved through simple firmware patches that improve Bluetooth stability and navigation accuracy.

Resolve 5.7L Hemi Engine Ticking and Performance Issues

The 5.7L Hemi V8 is a powerhouse, but it is not without its quirks. The most famous is the “Hemi Tick.” As an expert, I must emphasize that not all ticks are created equal. You must distinguish between a simple exhaust leak and a catastrophic lifter failure. Research shows that manifold bolt replacements are required every 40,000 to 60,000 miles for many 2014 units due to the bolts snapping under thermal expansion.

Manifold Bolts vs. Lifter/Cam Wear

If the rhythmic ticking noise disappears as the engine warms up, the cause is likely broken exhaust manifold studs. However, if the tick remains constant and is accompanied by a P0300 misfire code, you are likely facing a “dropped” lifter that has begun to eat into the camshaft. This is often the result of prolonged idling or infrequent oil changes. To debug this, a technician should perform a cylinder contribution test.

Another common engine failure in the 2014 model involves the water pump. These units are prone to premature bearing failure and coolant leaks. If you smell sweet coolant or see a puddle under the front-center of the truck, repair the water pump immediately to avoid overheating, which can lead to dropped valve seats—a death sentence for the Hemi engine.

Diagnose 8-Speed and 6-Speed Transmission Shifting Problems

The 2014 Ram 1500 used two primary transmissions: the venerable 65RFE 6-speed and the modern ZF-sourced 8HP70 8-speed. While the 8-speed is generally superior, it is not immune to issues. Many drivers experience a “kick” or “clunk” when coming to a stop as the vehicle downshifts from 2nd to 1st gear. This is often a software-level issue within the Transmission Control Module (TCM).

For those with the 6-speed transmission, “gear hunting” or slipping is a more common complaint. This usually points to a failing solenoid block or internal clutch wear. Regardless of which unit you have, always check for leaks from the transmission thermal management unit, which sits atop the transmission and can mix coolant with transmission fluid—a scenario that requires a total transmission rebuild.

Summary of NHTSA Recalls and Safety Concerns

Safety is paramount, and the 2014 Ram 1500 has been subject to several significant recalls. It is vital to visit the official guide at NHTSA to enter your VIN and verify completion of these campaigns. One of the most critical is the Takata airbag recall, where the inflators can rupture and send shrapnel into the cabin during an accident.

Other notable recalls include a software error that could prevent the cruise control from being canceled, and a physical issue with the tailgate latch that allowed it to fall open while driving. Perhaps most serious was the 2018 recall regarding the “Park” position interlock. In certain conditions, the vehicle could roll away if the brake wasn’t fully depressed when shifting. If your vehicle hasn’t been serviced for these issues, any authorized Ram dealer will perform the repairs free of charge.

Most 2014 Ram 1500 issues center on the air suspension system, TIPM electrical failures, and Hemi engine manifold bolts. Proactive maintenance and addressing software updates for the Uconnect and TCM can prevent many common glitches. Always verify your VIN against the NHTSA database to ensure critical safety recalls, such as the airbag and cruise control updates, have been performed. If you are experiencing any of these symptoms, consult a certified technician for a diagnostic scan to identify the specific fault codes before investing in major repairs.
