3.5L EcoBoost Specs by Year: HP, Torque & Towing 2011-2026 Chart

These 3.5 EcoBoost specs by year show how Ford’s twin-turbo V6 grew from 365 hp in 2011 to 400 hp in 2021. Torque climbed from 420 lb-ft to 500 lb-ft over the same period.

High Output and PowerBoost versions follow separate numbers, and the 2026 model year brings a reported drop to 382 hp. The chart below covers every F-150 model year, then explains why published figures disagree.

3.5 EcoBoost Specs by Year Chart for 2011 to 2026

This chart lists the standard 3.5L EcoBoost as sold in the Ford F-150. Each row shows output, torque, fuel injection, transmission, and compression ratio for that model year.

Ford announced the first rating in 2010. AutoGuide reported launch figures of 365 hp at 5,000 rpm and 420 lb-ft at 2,500 rpm, and that rating held through 2016.

Today the standard rating is higher. Ford’s 2025 F-150 specs page lists 400 hp at 6,000 rpm and 500 lb-ft at 3,100 rpm. Those headline numbers hide three separate rating changes, and each one has a cause.

3 Power Rating Changes Since 2011

Ford changed the standard output three times, in 2017, 2021, and 2026. Each change affects which row of the chart applies to your truck.

The 2017 Redesign

Ford’s July 2016 announcement raised the engine to 375 hp and 470 lb-ft. That was a gain of 10 hp and 50 lb-ft over the first-generation engine. The truck also moved to a 10-speed automatic in place of the six-speed.

Secondary spec sources also describe a switch from direct injection only to combined port and direct injection. They list compression rising from 10.0:1 to 10.5:1 on the standard engine.

The 2021 Power Increase

For 2021, Ford added 25 hp and 30 lb-ft to the standard engine. Hagerty’s coverage of the update lists 400 hp at 6,000 rpm and 500 lb-ft at 3,100 rpm. Peak power now arrives 1,000 rpm higher than it did in the 2017 to 2020 trucks.

The 2026 Filter Update

Reports for the 2026 model year put the standard engine at 382 hp, with torque unchanged at 500 lb-ft. PickupTruckTalk attributes the drop to a new gasoline particulate filter and cites a Ford spokesperson confirming the filter.

That outlet does not point to a Ford spec sheet for the 382 hp figure, so confirm it on your window sticker. Because sources differ, it helps to know where the conflicting numbers come from.

Why Published 3.5 EcoBoost Numbers Disagree

Many spec pages list different figures for the same model year. The mistakes follow three predictable patterns.

The first pattern is torque. Ford rated the 2017 engine at 470 lb-ft, yet some pages print 475 lb-ft for that year.

The second pattern mixes engines. The 510 lb-ft figure belongs to the High Output engine. Some pages attach it to the standard 2021 engine, which Ford rates at 500 lb-ft.

The third pattern is the High Output year range. Pages disagree on whether the Raptor version ended in 2021 or 2022, so treat open-ended ranges with caution.

When two sources conflict, trust Ford’s own announcements first. Then check the window sticker for your exact truck. Those mixed-up figures matter most for the two special versions, so they get their own comparison.

High Output and PowerBoost Versions Compared

This table separates the three versions so the numbers stop blending together.

Ford launched the High Output engine in the 2017 Raptor with 450 hp and 510 lb-ft. Ford also described a redesigned turbo system and combined port and direct injection for that engine.

The 2019 Limited then received the same engine. Coverage of that change reported a gain of 75 hp and 30 lb-ft over the 2018 Limited.

Reports on the 2021 Raptor show no change to those ratings. Peak power and torque do occur at different rpm than before.

PowerBoost is a hybrid powertrain rated at 430 hp and 570 lb-ft from 2021. Keep it out of the gas-only chart above. Oil capacity is the one spec that stayed steady on the standard engine.

3.5 EcoBoost Oil Capacity Is 6 Quarts

The standard F-150 3.5L EcoBoost takes 6.0 quarts of 5W-30 oil with the filter, and that capacity has not changed since 2011. Ford’s 2024 engine overview lists the same 6 quarts.

Only the Ford oil specification code moved between generations. See our 3.5 EcoBoost oil capacity chart by year for the exact code. Before you use any of these numbers, confirm which engine is under your hood.

4 Ways to Confirm Your Engine Version

A quick check keeps you from reading the wrong row. Decode the VIN first with our F-150 VIN engine code chart, then work through these steps.

1. Match your model year to the chart and note the standard rating.
2. Check whether your trim is a Raptor or a Limited, since those can carry the High Output engine.
3. Look for a PowerBoost badge or hybrid listing on the window sticker.
4. Compare the sticker or build sheet with the rating shown for your year.

If the sticker and a website disagree, the sticker wins. With the engine confirmed, the towing numbers are easier to read correctly.

3.5 EcoBoost Towing from 11,300 to 14,000 Pounds

Ford’s launch figures listed 11,300 pounds of towing for the 2011 F-150 with this engine. By 2021, coverage of the update lists a 14,000-pound maximum for rear-wheel-drive trucks with the Max Trailer Tow package.

Ratings vary by cab, bed, axle ratio, and drive type. Check the specs for your exact configuration. Those ratings round out the full picture of this engine.

Which 3.5 EcoBoost Specs Apply to Your Truck

Use the 3.5 EcoBoost specs by year above to match your model year to the right rating. The standard engine made 365 hp and 420 lb-ft through 2016. It moved to 375 hp and 470 lb-ft in 2017, then to 400 hp and 500 lb-ft in 2021. Oil capacity stayed at 6 quarts throughout.

The 2026 model year is reported at 382 hp, while High Output and PowerBoost trucks follow their own ratings. Treat your window sticker as the final word when a website disagrees with Ford. If you are shopping used, read our 3.5 EcoBoost problems guide to see how each generation holds up.

Frequently Asked Questions About 3.5 EcoBoost Specs

How Much Horsepower Does It Make

The standard F-150 3.5L EcoBoost makes 365 hp from 2011 to 2016 and 375 hp from 2017 to 2020. It makes 400 hp from 2021 to 2025. The High Output version makes 450 hp, and the 2026 standard engine is reported at 382 hp.

What Is the High Output Version

The High Output 3.5L EcoBoost makes 450 hp and 510 lb-ft of torque. Ford introduced it in the 2017 Raptor and later fitted it to the 2019 Limited. It uses a redesigned twin-turbo system and combined port and direct injection.

Did Torque Change in 2021

Yes. Ford raised the standard engine from 470 lb-ft to 500 lb-ft for 2021, along with a rise from 375 hp to 400 hp. The 510 lb-ft figure on some pages belongs to the High Output engine, not the standard one.

How Much Oil Does It Take

The F-150 3.5L EcoBoost takes 6.0 quarts of 5W-30 oil with a filter change. Ford’s 2024 engine overview lists the same 6 quarts. The Ford specification code changed between generations, so confirm the code for your model year before you buy oil.

Is PowerBoost the Same Engine

No. PowerBoost is a full hybrid V6 with its own ratings of 430 hp and 570 lb-ft from 2021. The gas-only 3.5L EcoBoost is rated lower. Treat the two as separate powertrains when you compare specs, towing, or service data.
